• Weighs approximately 2.7 kg (6.0 lbs).
• Rated torque at 0.8A is 10 Nm nominal (7.4 lb-ft).
• The operating speed is 120 rpm max.
• Operating temperature of -35℃ to + 80℃ (-31℉ to +176℉).
• Axial force limit of 1500 N max (337 lbf).
• Building moment limit of 50 Nm max (36.9 lb-ft).
• Current control is 12 VDC.
• Current (max) is 1.5 A peak.
• Current (continuous) is 1.0 A.
• Sensor resolution is 12 bit.
• Sensor linearity is +/- 1.2% full scale.
• Environmental Protection is IP66.
